Frame
Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
It’s easier because Prime keeps things simple. The reliability of an aluminium frame, perfectly balanced with the latest version of Bosch’s CX motor and components to instil confidence on your rides. Prime might be your first ebike but it certainly won’t be your last. Prime and Prime R come with 625Wh and 750Wh batteries respectively, 120mm Rockshox forks and the latest generation of ONOFF components including the Pija dropper post on the Prime R. You only have to choose your colour and your build as the fun is already guaranteed.
-
Sizes
XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
-
Fork
RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Stem
Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
-
Grips
Onoff Twin, 1lock-on, 135mm
Seatpost
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
-
Saddle
MDK ebike black
Front brake
Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Rear brake
Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
-
Rims
Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes
Mavic J-bend double butted, contactless lacing
-
Front hub
Mavic, Boost 15x110mm, IS 6 bolts
