Redesigned Platform Shape
- Platform size has increased compared to the F20 pedal (105 x 102mm usable)
- Careful consideration has been given to getting the right balance between foot stability and clearance in narrow gaps and ruts
- Asymmetric shape designed to give full support to the shoe sole, extending to areas the F20 platform didn’t
All New Pin Design
- Reverse loading design prevents pins coming loose and means you have a much better chance of removing them when you want to
- Unique hex shape for extra bite
- Height adjustable using supplied spacers
- Max pin height of 6mm
Concave Profile
- Dual concave profile helps hold the shoe on the platform and give a superior planted feeling
- Concavity enhanced by using shorter pins towards the middle of the platform and having no pin locations in the centre of the platform
Pedal Internals
- Proven internal layout of F20 pedal remains for smooth long-term durability
- Three cartridge bearings and an IGUS bush
- Internal and external sealing prevents any ingress of dirt and debris
- Fully serviceable and re-buildable
- Revised axle design for improved strength and impact resistance
